Aermatica3D Products

FTS - Flight Termination System

Aermatica3D has designed the flight termination system to fly in complex scenarios and to protect drone and payload from any flyaway according to the regulations required by ENAC and EASA.

Aermatica3D flight termination systems don’t need to be installed inside the aircraft and it’s not necessary to open the drone to install our product, so installing our product doesn’t invalidate any warranty and make our FTS easy to remove even during the operations. Aermatica3d’s FTSs have passed long laboratory tests to verify reliability in operating conditions, range tests, and flight tests that have demonstrated non-interference with the other devices in the system.

A non-invasive series test plan is performed on each FTS to validate the single specimen

FTS 300 - TERMINATORE DI VOLO MATRICE 300 RTK

FTS 300 – MATRICE 300 RTK FLIGHT TERMINATOR

Advantages

  • Flights sheltered from any flyaways;
  • Increased safety in operations;
  • Reduction of the risk of damage to the drone and its possible additions;
  • The parachute can be integrated into the FTS system (see photo)

The Aermatica3D flight termination system for DJI Matrice 300 drones consists of the remote control, a transmitter, and the onboard SLAVE receiver unit, complete with double CUT OFF for cutting power to the drone. The two onboard units communicate via a special connection cable.

According to the drone and the sensors installed, FTS 300 can be integrated with an emergency parachute to fly, according to the regulations set by ENAC and EASA, in complex scenarios sheltered from any flyaways for better safety for the drone and the sensors installed.

As prescribed by the regulations, the Flight Termination System, when activated via the REMOTE CONTROLLER, operates by cutting the power supply to the drone and stopping the flight through a communication channel utterly independent from that of Command and Control the drone.

The MASTER unit is configured to perform an automatic channel search when switched on by scanning all the available channels to position itself in a few seconds on the one freest from any interference.

Radio communication is also protected by cryptographic keys, which prevent any attempts to by third parties to violate the radio code and any intervention on the on-board unit.

FTS 200S – MATRICE 200 SERIES FLIGHT TERMINATION SYSTEM (M200 / M210 / M210 RTK, V1 e V2)

Advantages

  • Total weight 150 g
  • Conformity with regulations for critical scenarios
  • Flights sheltered from any flyaways
  • Increased safety in operations
FTS 200S – TERMINATORE DI VOLO SERIE MATRICE 200
FTS 200S – TERMINATORE DI VOLO SERIE MATRICE 200 - kit

The system is based on a remote controller, a transmitter, and a SLAVE receiving unit on board associated with a double CUT OFF to cut the drone’s power supply. The two onboard units communicate via a special connection cable.

As prescribed by the regulations, the Flight Termination System, when activated via the REMOTE CONTROLLER, operates by cutting the power supply to the drone and stopping the flight through a communication channel utterly independent from the drone controller.

The MASTER unit is configured to perform an automatic channel search when switched on by scanning all the available channels to position itself in a few seconds on the one freest from any interference.

Radio communication is also protected by cryptographic keys, which prevent any attempts to by third parties to violate the radio code and any intervention on the on-board unit.

FTS 600 - TERMINATORE DI VOLO MATRICE 600 e BLY-C

FTS 600 – FLIGHT TERMINATION SYSTEM MATRICE 600 AND BLY-C

Advantages:

  • Compatible with M600 and Aermatica3D BLY-C family drones
  • Flights sheltered from any flyaways,
  • Increased safety in operations
  • The parachute can be integrated into the FTS system (see photo)

The FTS 600 compatible with both DJI’s Matrice 600 drones and Aermatica3D’s BLY-C drones can be combined with an emergency parachute for sensors and drone’s safety and to be able to fly in complex scenarios protected from any Flyaway and according to ENAC and EASA regulations.

The system consists in the remote control, a transmitter, and the SLAVE receiving unit on board, complete with double CUT OFF to cut the drone’s power supply. The two onboard units communicate via a special connection cable, moreover the radio controller and the Flight Termination System coupled and coded to be able to use multiple FTS without any interference.
